Part of the keebx engineering log.
💤 I’ll dig deeper in the USB hub feature later…
The embedded USB hub will offer the possibility to plug USB devices like a mouse wireless receiver, or a USB key. The Pico will internally by wired as a permanent device of the HUB.
| Name | Type | Link |
|---|---|---|
| nanohub | PCB | https://muxtronics.nl/nanohub.html |
| hub20 | Keyboard with embedded HUB | https://github.com/joshajohnson/Hub20/tree/master |
| / | keyboard embedded HUB schematic | https://imgur.com/a/lYkOHke |
| USB7050P | controller chip | https://www.microchip.com/en-us/product/USB7050P |
| CYUSB4347-BZXC | controller chip | https://www.infineon.com/cms/en/product/universal-serial-bus/ez-usb-hub-controllers/ez-usb-hx3pd-usb-10-gbps-hub-controller-with-usb-power-delivery/cyusb4347-bzxc/#!?fileId=8ac78c8c85ecb347018653965cd43d7f |
